SPECIFICATION

1,Working Medium:Air source

2,Body material:Aluminum die-casting

3,Filter bowl and Lubricator bowl material:PC

4,Filter element material:Brass

5,Bowl Guard:Aluminum alloy

6,Seal Material:NBR

7,Adjustabing knob:POM

8,Working pressure:0~1.0MPa

9,Working Temperature:5~60℃

10,Filtration fineness:40µ

11,Mounting type: Pipe mounting or bracket support mounting

12,Regulator type:Diaphragm type

13,Lubricator type:Oil volume adjustable during working

14,Port size:G1/4

15:Design type:Modular
